Ford F-250 Camper Shell | ARE Truck Caps
Our F-250 camper shell is engineered specifically for the Ford Super Duty platform, delivering commercial-grade protection and full bed access for work trucks and recreational haulers alike. Built with reinforced RTM fiberglass composite and a welded aluminum frame, this camper shell withstands decades of heavy use while maintaining a factory-quality finish.
Every unit ships with our proprietary three-point weather seal system, automotive-grade paint matched to Ford OEM colors, and a lifetime structural warranty. Whether you’re securing tools on the jobsite or converting your bed into sleeping quarters for weekend adventures, the F-250 camper shell transforms your Super Duty into a fully enclosed cargo platform.
- RTM fiberglass composite shell with UV-resistant gelcoat finish
- Welded aluminum internal frame rated for 300 lb roof load capacity
- Three-point bulb seal system for dust and water intrusion prevention
- Factory-matched automotive paint in all Ford Super Duty OEM colors
- Side window configurations: sliding, flip-out, or solid panel options
Materials and construction
We build every f250 camper shell with RTM (Resin Transfer Molding) fiberglass composite, a manufacturing process that produces consistent wall thickness and superior impact resistance compared to hand-laid fiberglass. The outer gelcoat layer includes UV inhibitors that prevent fading and oxidation even after years of sun exposure.
The internal skeleton uses marine-grade welded aluminum extrusions at all stress points, creating a cage structure that distributes roof loads across the truck bed rails rather than concentrating force at mounting clamps. This frame design allows the shell to support roof-mounted cargo carriers, rooftop tents, and ladder racks without flexing or cracking the fiberglass body.
Window and door configurations
The F-250 camper shell ships with your choice of three side window styles. Sliding windows use dual-pane tempered glass in extruded aluminum tracks, providing ventilation without removing screens or panels. Flip-out windows operate on friction hinges and include removable bug screens for maximum airflow during camping. Solid panel sides eliminate glass entirely for maximum security on work trucks.
Our full walk-in rear door spans the entire tailgate opening, secured by dual stainless steel rotary latches that engage weatherstripping on all four edges. Two gas struts hold the door at any angle from 30 to 90 degrees, making it easy to load awkward cargo or access the bed from a standing position. The door’s interior panel includes molded pockets for small tools and a recessed dome light switch.
Weatherproofing and bed seal system
We seal the F-250 camper shell to your truck bed using a three-stage bulb seal system. The primary seal runs continuously along the bottom rail flange, compressing against the bed rail top surface when you tighten the mounting clamps. A secondary D-bulb seal at the cab/shell junction prevents water from migrating forward during heavy rain or pressure washing.
The rear door uses a triple-wiper seal design: an outer bulb seal contacts the door frame, a center foam seal fills the gap behind the latch, and an inner wiper blade sheds water away from the cargo area. This system maintains a watertight seal even when driving through heavy rain at highway speeds.
Shop more Super Duty truck cap models
What people are saying
Ford F-250 camper shell questions
Yes, the shell fits over factory spray-in bedliners and most aftermarket liners like Line-X or Rhino Lining. We include shimmed clamp spacers that account for the additional thickness of the liner material on your bed rails.
The mounting clamps sit on top of the bedliner at the rail surface, and the bottom seal compresses against the liner texture to maintain a weathertight bond. You do not need to remove or modify your existing bedliner for installation.
The standard F-250 camper shell supports up to 300 pounds of static roof load, which accommodates most two-person rooftop tents when mounted to crossbars in the integrated roof channels. Dynamic load capacity while driving is 165 pounds.
For heavier rooftop tent models or if you plan to store additional gear on the roof, we offer a heavy-duty roof upgrade kit that increases static capacity to 500 pounds. This upgrade must be specified at the time of order as it requires additional internal bracing installed during manufacturing.
We paint every shell using Ford’s OEM paint codes, which are listed on the driver’s door jamb sticker on your truck. When you order, provide us with your truck’s paint code (a two or three character code like M7 or YZ), and we’ll mix the exact base coat formula Ford uses at the factory.
Our paint process includes three coats of primer, two base coats, and two UV-resistant clear coats, wet-sanded and buffed to match Ford’s factory orange peel texture. Metallic and tri-coat colors like Carbonized Gray or Iconic Silver receive an additional mid-coat layer to match the factory depth.
No drilling is required. The shell mounts using C-clamps that grip the bed rail top surface, secured with hex bolts that tighten against the rail’s inner edge. The entire installation is removable and leaves no permanent modifications to your truck.
The mounting system uses eight clamps total (four per side) that slide into position along the shell’s bottom rail. Each clamp compresses the weatherstripping bulb seal against your bed rail as you tighten the bolts, creating a waterproof bond without adhesives or fasteners penetrating the truck bed.
Yes, the camper shell has adequate interior height to clear most under-bed fifth-wheel hitch systems, including the Ford factory Puck System and aftermarket slider hitches. The shell’s front edge sits approximately 2 inches behind the cab, leaving clearance for the hitch head to raise and lower.
If you use a gooseneck ball, you’ll need to remove the ball before closing the tailgate when the shell is installed, as the ball extends higher than the bed rail. Fifth-wheel hitches with folding heads do not require removal.
Our lifetime warranty covers the fiberglass shell body and welded aluminum frame against cracks, delamination, and structural failure for as long as you own the truck. This includes defects in materials, manufacturing flaws, and frame corrosion.
The warranty does not cover paint fading (covered separately for 5 years), accidental damage, normal wear on weatherstripping and seals, or failures caused by exceeding the 300-pound roof load rating. Glass breakage and latch mechanisms carry a 3-year warranty from the date of purchase.
The 6.75-foot bed shell weighs approximately 185 pounds, and the 8-foot bed version weighs 210 pounds. Weight varies slightly depending on window configuration, with solid panel sides being about 15 pounds lighter than shells with sliding glass windows.
Two people can lift and position the shell onto the truck bed rails without mechanical assistance. We recommend having three people for installation to ensure even placement and to hold the shell steady while tightening the mounting clamps.
